ENGLISH
Using the Remote Controller
Aim the Remote Controller at the Remote
Control Sensor on the Movie Camera and press
the appropriate button.
Distance to the Movie Camera: Less than 5 metres.
Angle: Approximately 15° up, down, left and right
from centre axis.
•The operative range described above is valid for using the
Remote Controller indoors. When using it outdoors or under
strong lights, it may not work correctly even within the above
range.
•Within a distance of about 1 metre, it is also possible to use
the Remote Controller from the side ([MENU] Button side).
Selecting the Remote Controller Mode
When using two Movie Cameras at the same time, selecting
different Remote Controller Modes makes it possible to
operate them separately.
• If the Remote Controller Mode set on the Movie Camera and
on its Remote Controller are not matched, the [REMOTE]
Indication appears.
Setting to Be Made on the Movie Camera;
Set [REMOTE] on the [OTHER FUNCTIONS] Sub-Menu to
the desired Remote Controller Mode.
Setting to Be Made on the Remote Controller:
[VCR1]: Press the [!►] Button and [■] Button
simultaneously. O
[VCR2]: Press the [^i] Button and [■] Button
simultaneously. Q
• Replacing the batteries in the Remote Controller
automatically resets it to the [VCR1] Mode.
