ENGLISH
1 i|§[POWER]Fjf1llKM<i[CAMERA](ail
§m) mycR]{mm§m)
-
■ ^lai^iliCAMCRAi
s'f
' ■ ''i:
\-'
=
-'-Rvi ■: -
■ 7 -i.R-''
:_GVi
= .S:^5i .-
• 7-:R^iif;.^t.A^:i7=2^:rS:xZ*-€!7^ ' 22-
IRpMOTpi ;i?2 ■
^
•
-2- ■ ^ 2 4; 2
VC^2--^ .
•
■ 2ttzz2f2'Rl-2i^z^
2-
(-► 132)
2'CAL’FRA M-NR3i=2^z;, VCn MENU3^2 2 ;
:HLrJOfE:izEtr2^sF;22?j,J-n^ r
;vcMii 23 :
I-|ii-v,'Bii5 - O
'vCrAA 2t=2'>i!l”":;B2:: ° ©
■ Using the Remote Controller
1
Set the [POWER] Switch to [CAMERA] or
[VCR].
When you want to perform recording operations, set
the switch to (CAMERA); and when you want to
perform playback operations, set it to [VCR]
2
Aim the Remote Controller at the Remote
Control Sensor on the Movie Camera and
press the appropriate button.
Distance to the Movie Camera; Less than 5 metres.
Angle; Approximately 15' up, down, left and right
from centre axis.
• The operative range described above is valid for using
the Remote Controller indoors.
When using it outdoors or under strong lights, it may not
work correctly even within the above range.
• Within a distance of about 1 metre, it is also possible to
use the Remote Controller from the side (LCD Monitor
side).
Selecting the Remote Controller Mode
When using two Movie Cameras at the same time,
selecting different Remote Controller Modes makes it
possible to operate them separately.
• If the Remote Controller Mode set on the Movie Camera
and on its Remote Controller are not matched, the
[REMOTE] Indication appears.
• Replacing ttie button-type battery in the Remote
Controller automatically resets it to the [VCR1] Mode.
• Set [REMOTE] on the Menu to the desired Remote
Controller Mode.
{-¥
132)
Setting to Be Made on the Movie Camera:
Set [REMOTE] on the [CAMERA MENU3] Menu or on the
[VCR MENU2] Menu to the desired Remote Controller
Mode.
Setting to Be Made on the Remote Controller:
[VCR1]: Press the [I'-] Button and [■] Button
simultaneously. O
[VCR2]: Press the [-«(] Button and [■] Button
simultaneously. ©
-108-
