ENGLISH
• -r; .jjS£ ^ fS ^ A II^ ix A %I^^J ’= B
MUUQ.,,; , ifri'lA-'T'^O 01
VA'a!^A'i:.>- AA >‘"'1^ ’ ■ FA-^fr
■ rp^lTT'";^CC1-Ali^AFfiL^N^
aa O^.-;A O-^F ■ a A '
zEB ■ c.
• Aiv;-;|f'^A'.^, -LilA -5;' 30 5 5. "'A l A ¿A IS a 5P
A ■ An - -
• KAATH A5A345 AfiAFTiilAwA ■
-a ■ ^
• A A A : f ■ I'AA:
■Wi-AAiW Tl^Aii^EO .
>7 A ■ ^
m 'VW-SKOE ■ ■5?§IA EE ■
A??itAiSAtiSO^''^ ■ A A A.ii^ AW
VMSIE ■ A 1^1 A ^
• W A A A i i - ^ .
-A A A^AAiSAiA-/ .*I; a V one touch STATIOU| a
cHMicc^A'f^' Aio. = w w A w T . mnm^.^E^:rn.
154-
■ LCD Monitor/FInderA-ens Hood/
Shoe Adaptor/Microphone Socket
LCD Monitor
• In places where big changes in temperature occur,
condensation may form on the LCD Monitor. Wipe it with
a soft, dry cloth.
• When the Movie Camera is very cold when it is turned
on, the picture on the LCD Monitor is initially a little
darker than normally. However, as the internal
ternperature rises, the LCD Monitor regains its normal
brightness.
• Extremely high precision technology is employed in
producing the LCD Monitor. The result is more than
99,99% effective pixels with a mere 0.01% of the pixels
inactive or always lit.
Finder
• Extremely high precision technology is employed in
producing the Finder screen. The result is more than
99.99% active pixels, with a mere 0.01% of the pixels
Inactive or always lit.
• Do not leave the Finder or the Lens aimed at the sun.
This could seriously damage internal parts.
Lens Hood
• When you want to attach a filter or conversion Lens with
a diameter of 30.5mm. be sure to first remove the Lens
Hood by turning it counterclockwise.
•When you want to attach a filter with a diameter of 34mm.
attach it without removing the Lens Hood.
• During recording with a filter or conversion lens attached,
the tour corners of the picture may become dark
(vignetting effect), when you push the [W/T] Zoom Lever
toward [W].
For details, please also read the operating instructions of
the accessory being used.
Shoe Adaptor
• When attaching the Shoe Adaptor {VW-SK9E; optional),
mount the Movie Camera toward the front end of the
Shoe Adaptor to prevent the Stereo Zoom Microphone
{VW-VMSIE; optional) from being recorded in the
picture.
Microphone Socket
• If you want to perform audio dubbing via an external
microphone or audio equipment, connect it to the [MIC]
Socket on the Output Terminal Box [AV ONE TOUCH
STATION], In this case, the Movie Camera’s built-in
microphone is turned off.
