[S-VIDEO OUT]
[S-VIDEO IN]
[AUDIO IN]
fP *
ENGLISH
e
(mm&) n
Omm^ii
When Connecting the Editing Controller
VW-EC1E (optional)
• When you use the Editing Controller VW-ECl F it is
not necessary to connect it to the Edit Socket on the
VCR. as the VCR’s operation is performed via infrared
remote control. Therefore, editing is also possible onto
VCRs not equipped with an Edit Socket,
• For the operation of the Editing Controller, refer to its
operating instructions.
Q To Edit Socket
0 Edit Socket
0 Connect the AC Adaptor,
0 VCR (not supplied)
© TV (not supplied)
116-
