Panasonic NV-DS77EN - Инструкция (Страница 14)

1 iP±®P/f^ ’ il§mrtbffiS$i]fLl«iie± ■
3 t32DfL«ig||±&^№^Z®?Em®II!ii3
4 №±ii^« 1 №iiS:i[to ’
a®® »
5 i^i£ifiiilT#1tff ■
es • aii^}t#KlS]±1if4 ”
6 ■ m(S]T
if» ' ”
-;S+S'i;BATT EJECT PUSHjim-'Ci'^Ti ■ ^ W : ^ ^ ] _ r
• • ^^[P0V^En]Ц^iiWíL\0=f^, -
: J ^ ^ r; ^ ^
1—3 it-mr °
t 1 - Lic:T ■ ^;:t3 2
■ ^.5“ ■ ' ~
ENGLISH
■ Supplying Power with the Battery
Before use, fully charge the Battery.
1 Place the Battery on the AC Adaptor as
shown above and slide it horizontally until
it stops.
2 Connect the AC Mains Cable to an AC
mains socket.
3 When all three Charge Lamps on the AC
Adaptor are lit, charging is finished.
The Charge Lamps [50%], [80%j and [100%] flash
and then remain lit one after another.
These lamps Indicate the approximate charging
condition reached.
4 Remove the Battery by sliding it in the
opposite direction of Step 1 above.
Also disconnect the AC Mains Cable.
5 Slide the Finder backward to its fully
extended position and then tilt it upward.
G Insert the Battery into the Battery Holder
on the Movie Camera and slide it
downward until it locks with a click.
Removing the Battery from the Movie Camera
While pressing the [BATT.EJECT PUSH] Button, slide the
Battery upward to remove it.
• Be careful not to drop the Battery by accident.
• Before removing the Battery, set the [POWER] Switch
to [OFF],
Charging Two Batteries
If you attach two Batteries to the AC Adaptor, they will be
charged one after the other.
To charge, follow Steps 1-3 above.
• Charging starts from Battery 1. At this time, the Charge
Lamps for Battery 2 show the remaining charge in the
Battery 2. (If the remaining charge is less than 50%, no
.“ 10- Charge Lamp is lit.)
