Replacing the oven lamp
1. Unplug the power
cable.
2. Then, remove the
protective glass cover
of the lamp inside your
oven by turning it
counterclockwise.
3. Then, remove the bulb by turning it
counterclockwise.
4. After installing the correct bulb obtained from
an Authorized Service, reinstall the protective glass
of the lamp.
For the square-shaped lamp models:
There are 2 square-shaped lamps at right and
left side
of the oven
inside. Both
lamps are on and
off at the same time.
Replacing the
Oven Lamp
Disconnect the appliance from
the supply Take out screws on the side shelve
Take out Lens of the oven lamp by means of
the flat screwdriwer
Replace defective lamp with the new one.
Reinstall lens and side sheelf. Lamp type is
220-230V, 15/25WE14,T300°C
(In models with lamp): Replacing the oven door
2. Open the latches placed on
the hinges both sides of the
front door until they touch the
support pins.
3. Close the front door till
touching the latches.
%
^------------- 1 ------ —---- ^
1. Open the front door to 90°
4. Hold the oven
door slightly at the
handle, close
slightly, pull
upwards and
close until there is
a aperture of few centimeters
are left. Then you can detach
the hinges from the housing.
The mount the door;
Do the above started instructions in reverse
order.
Attention: A sure that hinges are placed
apropirately in the housing do not target to close
the latches.
