Part 3l
T e c h n i c a l s p e c i f i c a t i o n s
1. Burners plate
2. Control panel
3. Front door
4. Handle
5. Storage compartment
6 . Tray
7. Grill shelf
8 . Integral air oven
Conventional
cookers Multi-function
cookers
Fan assisted
cookers
Grill wattaae 800/1500 800/1500 800/1500
Oven wattaae 1900W 1900W 1900W
Turbo wattaae - 1800W -
Turbo motor - + +
Lamo 25 W 25 W 25 W
External dimensions H: 850 H: 850 H:850
W: 500 W: 500 W: 500
D: 600 D: 600 D: 600
1. 0 140 1200 W Radian plate_____________
2. 0 140 1200 W Fast radian plate
3. 0 180 1700 W Radian plate_____________
4. 0 180 1800 W Fast radian plate
5. 0 140x250 2000 W Fast radian plate
6. 0 180 2000 W Rapid plate (*)
7. 0 145 1000 W Solid plate
8. 0 145 1500 W Rapid plate (*)
9. 0 180 1500 W Solid plate ~vr
10. 0 80 450 W solid plate
There may also be plate location other than the ways shown
in the figures.
The fast radian, extended and dual plates burn with that
brillant light when they are first ON.
A rapid heating solid plates are as denoted by a red spot
in the centre of the plate.
The voltage, frequency and maximum powers shown in the
data plate .
11. 0 180 1000 W Solid plate______________
12. Rapid burner 2.9 kW__________________
13. Semi rapid burner 2.0 kW_____________
14. Auxiliary burner 1.0 kW
15. 0 120x180 700-1700 W dual plate
© @
1
(*) protector
