Panasonic NV-VS3EN - Инструкция (Страница 26)

I ____
I 0 Id i tal e f t c c t
J T I TLE S E T U P
i . D A T E / T I M E S E T U P
i O T H E R F U N C T I O N S
a L C D ^ E V F S E T U P
mmmmmm
1 »(MENUHIS'W) iBo
[CAMERA]
o •
[VCR]
»«)[AT]g|--^3i*BilE3Sg*
4 fgSl{AT]ii'finilgMS3S№S«
5 ^ [SET] m > «
mmmm
[MENU] 19 •
• [DATE/TIMESETUPK T?i?W (-» 56) ^ [LCD/
EVFSETUP](i®HRS.T^£^«S/«i^«(SS6$)iS?iM-^40)
№®5i9i(fei6a • •
M - a«iisss^m •
wigis) m • -
ENGLISH
Using the Menus
This Movie Camera displays the settings of various functions
in menus to make it easy to select frie desired functions and
settings.
1 Press the [MENU] Button.
When you press this button while the (CAMERA] Lamp is
lit in red, the Camera Mode Menu O appears.
When you press this button while the [VCR] Lamp is lit in
green, the VCR Mode Menu 0 appears.
2 Turn the [ A T ] Dial to select the desired sub­
menu.
Turning the [A ▼] Dial changes the highlighted item.
3 Press the [SET] Button to display the selected
sub-menu.
4
Turn the [ A T ] Dial to select the item to be set.
5 Press the [SET] Button to set the selected Item
to the desired mode.
Exiting the Menu
Press the (MENU] Button again.
•The method for making settings on the (DATE/TIME SETUP]
Sub-Menu (-♦ 56) and [LCD/EVF SETUP] Sub-Menu {-¥ 40)
differs silghtly from that of other Sub-Menus.
•You can display the menu during playback, but not during
recording. Also, it is possible to start playback while the
menu is displayed, but if you start recording, the displayed
menu disappears.
•The settings that you have selected on the menus are
maintained when you turn the Movie Camera off. However, if
you disconnect the power supply unit (Battery or AC
Adaptor) from the Movie Camera before turning it off, the
selected settings may not be maintained.
30
