31
mode or changing fan speed, this function will be canceled automatically.
+ button
For presetting temperature increasing.
Press this button, can set up the temperature, when unit is on. Continuously press
and hold this button for more than 2 seconds, the corresponding contents will be
changed rapidly, until unpress the button then send the information, ºC is display-
ing all along. In Auto mode, the temperature can not be set up, but operate this
button can send the signal. Centigrade setting range :16-30; Fahrenheit scale
setting range 61-86.
- button
Presetting temperature can be decreased.
Press this button, the temperature can be set up, continuously press this button
and hold for two seconds, the relative contents can quickly change, until unhold
this button and send the order that the ºC signal will be displayed all the time.
The temperature adjustment is unavailable under the Auto mode, but the order
can be sent by if pressing this button.
LIGHT button
Press this button at unit On or Off status, Light On and Light Off can be set up.
After powered on, Light On is defaulted.
swing up and down button
Press this button, to set up swing angle, which circularly
changes as below:
This is an universal use remote controller.
If remote controller sends the following three kinds of status that
the swing status of main unit will be:
When the guide louver start to swing up and down, if turn off the Swing, the air
guide louver will stop at current position.
which indicates the guide louver swings up and down between that all five
positions.
TIMER ON button
Timer On setting: Signal “ON” will blink and display, signal will conceal, the
numerical section will become the timer on setting status. During 5 seconds blink,
by pressing + or - button to adjust the time value of numerical section, every press
of that button, the value will be increased or decreased 1 minute. Hold pressing
+ or - button, 2 seconds later, it quickly change, the way of change is:
During the initial 2.5 seconds, ten numbers change in the one place of minute,
then the one place is constant, ten numbers change in the tens place of minute
at 2.5 seconds speed and carry. During 5s blink, press the Timer On button, the
timer setting succeeds. The Timer On has been set up, repress the timer On but-
ton, the Timer On will be canceled. Before setting the Timer, please adjust the
Clock to the current actual time.
TIMER OFF button
Once press this key to enter into TIMER OFF setup, in which case the TIMER OFF
icon will blink. The method of setting is the same TIMER OFF as for TIMER ON.
