ENGLISH
1 ^±«)&<>
•
■ -jis
—iS)f li) °
• [POWER](«S) ® © iP[CHARGE](?ED tf Omm
is • » (fflMNv-vs50)
[POWER]®© KiE ■ St[CHARGE]@0tfer?SteF/v1
S ' " (fflMNV-VS70)
• jpSBPiies^Tmife • [CHARGE]®© til ■ a
3 fiic±ai^i8i ■ jt#«ixai«
ft-
«£#»3^ti±3lth«5teB#
■ 36®ti5lA^;f !!)[◄ BATTERY
EJECT]SO ■ lB]afSai«>1^ "
• • aa§[CAMERA/OFF/VCR]raP5§SiE[OFF] •>
■ ?E«iSí^i®[CHARGE]
MJ5(fll®MNV-VS70): lEt^Em
W« (NV-VS50): ES^l;
(NV-VS70): • HBnliiliiSIc.
»
(*>-fee?c;i:ii^30iTa»)
Supplying Power with the Battery
Charge the Battery before using it.
1
Attach the Battery.
•Align the Battery with line O P^sh it In the
direction of the arrow while holding it down.
•When charging, do not connect the DC Input Lead to
the AC Adaptor.
2
Connect the AC Mains Lead to the AC Adaptor
and an AC mains socket.
•The [POWER] Lamp 0 and the [CHARGE] Lamp ©
light and charging starts, (for NV-VS50)
The [POWER] Lamp © lights and then the [CHARGE]
Lamp © flashes and charging starts, (for NV-VS70)
• If the [CHARGE] Lamp © does not light even though
the Battery is attached, remove the Battery and then
re-attach it.
3
Remove the Battery by sliding it in the
opposite direction of Step 1 above.
4
Insert the Battery with its top (so that the arrow
points upward) into the top Battery Holder and
press the bottom of it toward the Movie
Camera until it locks with a click.
Removing the Battery from the Movie Camera
Hold the Battery firmly to prevent it from dropping and pull it
off while sliding the [◄BATTERY EJECT] Lever © in the
direction of the arrow.
• Before removing the Battery, set the [CAMERA/OFFA/CR]
Switch to [OFF].
■ Charging Lamp [CHARGE]
Flashing (NV-VS70 only): During charging
Lit (NV-VS50):
During charging
Lit (NV-VS70): The Battery can already be used to
operate the Movie Camera but it is
not yet fully charged.
(Approx. 30-minute battery charge)
Off: The Battery is fully charged.
-20-
