ENGLISH
Using the Finder
Before using the Finder, adjust it to your eyesight so that
the indications in the Finder are clear and easy to read.
1
Set the [POWER] Switch to [CAMERA] or
[VCR].
While pressing the centre button, slide the switch to
[CAMERA] or [VCR].
2
Slide the Finder backward completely and
then tilt it upward.
Do not pul! on the Eyecup to extend the Finder.
The Finder can be tilted upward by up to
approximately 75°.
O
Adjust by turning the Eyepiece Corrector
Lever Q.
It is also possible to adjust the brightness of the
Finder with the item [LCD/EVF SET] on the
[CAMERA MENUS] Menu or [VCR MENU2] Menu
(-» 142).
Using the LCD Monitor
You can also record while viewing the picture on the
opened LCD Monitor.
H Set the [POWER] Switch to [CAMERA] or
[VCR].
While pressing the centre button, slide the switch to
[CAMERA] or [VCR].
^ Press the [PUSH OPEN] Button and turn
out the LCD Monitor by approximately 90“
in the direction of the arrow.
The Finder turns off.
Adjusting the Angle
3
Adjust the angle of the LCD Monitor
according to the recording angle.
•The LCD Monitor rotates upward a maximum of
180°
Q
and downward by a maximum of 90° ©
from its normal vertical position. Trying to forcefully
rotate it beyond this range could seriously damage
the Movie Camera.
• It is also possible to adjust the colour saturation
and brightness of the LCD Monitor with the item
[LCD/EVF SET] on the [CAMERA MENUS] Menu
or [VCR MENUS] Menu (-► 142).
Closing the LCD Monitor
Push the LCD Monitor close until the [PUSFI OPEN]
Button locks with a click.
