1
1 ^
So
1
QO%J
POWER
[2 ^ ^ 1QO%J
$p±nm^ ’ }if «iteaiii5E;jisisgig± ’
m ’
°
^S®ft[50%] ■ [80%]iP[100%]#P4^ ’
'BM—m
fe
°
SXtlj °
m ’ mmmu\s\±mm °
6
H§«iteiiAJl&^ii1i±6^ffl>ti3)l > MRTii
a -
°
-ji®ttlBATT.EJECTPusH](i:>M#tb)ii ’
MKPh °
•
’ tf;if[PowER]ifliiiSM4[OFF]»
Fiip«>t!3SiA:xpiEifitgS0# ’
?
es
°
A»a# ’
1 -3
”
•
1
»itkB# ’
2 №*JMSm(liSatlSMi£i3 50 %0# ’
is) °
ENGLISH
■ Supplying Power with the Battery
Before use, fully charge the Battery.
1
Place the Battery on the AC Adaptor as
shown above and slide it horizontally until
it stops.
2
Connect the AC Mains Cable to an AC
mains socket.
3
When all three Charge Lamps on the AC
Adaptor are lit, charging is finished.
The Charge Lamps [50%], [80%] and [100%] flash
and then remain lit one after another.
These lamps indicate the approximate charging
condition reached.
4
Remove the Battery by sliding it in the
opposite direction of Step 1 above.
Also disconnect the AC Mains Cable.
5
Slide the Finder backward to its fully
extended position and then tilt it upward.
6
Insert the Battery into the Battery Holder
on the Movie Camera and slide it
downward until it locks with a click.
Removing the Battery from the Movie Camera
While pressing the [BATT.EJECT PUSH] Button, slide
the Battery upward to remove it.
• Be careful not to drop the Battery by accident.
• Before removing the Battery, set the [POWER] Switch
to [OFF].
Charging Two Batteries
If you attach two Batteries to the AC Adaptor, they will be
charged one after the other.
To charge, follow Steps 1-3 above.
•Charging starts from Battery 1. At this time, the Charge
Lamps for Battery 2 show the remaining charge in the
Battery 2. (If the remaining charge is less than 50%, no
Charge Lamp is lit.)
-18-
