Start-up
15
Actual value
Authorised value
Load carrying capacity
obtained via
according to the manual
of the 2 tyres
the calculation
or registration documents
on each axle
M
INIMUM FRONT
Frb(min) =
BALLAST
T
OTAL WEIGHT
W(tot) =
less than
or equal to
F
RONT AXLE
Fal(tot) =
less than
less than
LOAD
or equal to
or equal to
R
EAR AXLE
Ral(tot) =
less than
less than
LOAD
or equal to
or equal to
GB
Tractor
a) Checking the tractor’s required characteristics
.
The tractor requirements relate to:
- the total authorised weight
- the permitted weight per axle
- the authorised support weight on the tractor's coupling point
- the permissible load carrying capacity for the tyres fitted to the tractor
All of this information can be found on the data plate or on the registration papers and in the tractor manual.
.
The weight on the tractor's front axle should be at least 20% of the unladen weight of the tractor.
.
The tractor must supply the deceleration power (braking) required by the manufacturer when the machine is coupled
up to it.
.
The gross weight of the tractor indicated on the vehicle’s registration papers must be greater than the sum of:
- the unladen weight of the tractor
- the ballast
- the total weight of the towed machine
D
Uw
kg
Unladen weight of tractor
Fal
kg
Front axle load when the tractor is empty
Ral
kg
Rear axle load when the tractor is empty
Frb
kg
Front ballast (if present)
Lt
kg
Load transfer of the towed machine
a
m
Distance between the centre of gravity of the front
implement or ballast and the centre of the front axle (total of
a1 + a2)
a1
m
Distance between the centre of the front axle and the centre
point of the front lower linkage arms
a2
m
Distance between the centre point of the front lower linkage
arms and the centre of gravity of the front implement or
ballast
b
m
Wheelbase of tractor
c
m
Distance between the centre of the rear axle and the centre
point of the front lower linkage arms
cf the tractor's registration
documents or its instruction
manual
cf
ballast characteristics
cf
page 87
cf
characteristics of the different
elements or measure
cf the tractor’s instruction manual
or measure
cf
characteristics of the different
elements or measure
cf
the tractor's registration documents
or its instruction manual
cf the tractor's registration documents
or its instruction manual
The method on page 14 will enable you to complete the table below.
