94
En
Remote control features
■ Selecting a component to be controlled
You can select a component to be controlled
independently of the input source selected with the input
selector buttons.
Press 6
SELECT k / n repeatedly to select the
desired component.
The name of the component to be controlled appears in the
display window (6) on the remote control.
■ Controlling optional components
(Option mode)
“OPTN” is an optional component control area that can be
programmed with remote control functions independently
from any input source. This area is useful for
programming commands that are to be used only as a part
of a macro function or for components that do not have a
valid remote control code.
To select the option mode, press 6
SELECT k / n
repeatedly until “OPTN” appears in the display
window (6) on the remote control.
You cannot set a remote control code for the optional area. See
page 96 to program buttons operated within this component
control area.
You can control other components by setting the
appropriate remote control codes. Codes can be set up for
each control area. For a complete list of available remote
control codes, refer to “List of remote control codes” at
the end of this manual.
The following table shows the default component
(Library: component category) and the remote control
code for each control area.
Remote control code default settings
You may not be able to operate your Yamaha component even if a
Yamaha remote control code is preset as listed above.
In this case, try setting another Yamaha remote control code.
1
Set the operation mode selector to
F
SOURCE and then press an input selector
button (5) to select the control area you
want to set up.
Note
SELECT
SELECT
Setting remote control codes
Control area
Component
category
Manufacturer
Default
code
TUNER TUNER Yamaha 2602
A TAPE Yamaha 2700
B LD Yamaha 2200
C TUNER Yamaha 2607
V-AUX/
DOCK
TUNER Yamaha 2606
DTV/CBL TV – –
CD CD Yamaha 2300
MD/CD-R CD-R Yamaha 2400
DVD DVD Yamaha 2100
DVR DVR Yamaha 2807
VCR VCR – –
PHONO TV – –
Note
V-AUX/DOCK
DVD VCR DVR PHONO
DTV/CBL CD MD/CD-R
TUNER C B A
TV
SOURCE
AMP
