100
En
Remote control features
■ Programming macro operations
You can program your own macro and use the macro
programming feature to transmit several remote control
commands in sequence at the press of a button. Be sure to
set up remote control codes or perform learning operations
before programming the macro.
• The default macro is not cleared when a new macro is
programmed for a button. The default macro can be used again
when the programmed macro is cleared.
• It is not possible to add a new signal (macro step) to the default
macro. Programming a macro changes all macro contents.
• We do not recommend programming continuous operations
such as volume control in a macro.
1
Set the operation mode selector to F
AMP or
F SOURCE and then press CMACRO using
a ballpoint pen or similar object.
“MCR ?” appears in the display window (6) on the
remote control.
If you do not complete each of the following steps within 30
seconds, the macro programming mode will be
automatically canceled. In this case, start over from step 1.
2
Press the macro button you want to use to
operate the macro.
The macro button name (e.g. “M;DVD”) and the
selected component name (e.g. “DVD”) appear
alternately in the display window (6) on the remote
control.
“AGAIN” appears in the display window (6) if you press a
button other than a macro button.
3
Press the buttons for the functions you want
to include in the macro operation in
sequence.
You can set up to 10 steps (10 functions). After you
have set 10 steps, “FULL” appears and the remote
control automatically exits the macro mode. The
following example is for programming the following
procedure:
Step 1 (“MCR 1”): Press POWER.
Step 2 (“MCR 2”): Press DVD.
Step 3 (“MCR 3”): Press AUDIO.
To change the selected control area, press 6SELECT k / n .
Pressing the input selector buttons will program a macro step,
whereas
6SELECT k / n only changes the selected control
area.
4
Press C
MACRO again using a ballpoint pen
or similar object when the operation
sequence you want to program is complete.
“ERROR” appears in the display window (6) if you press
more than one button simultaneously.
Notes
Note
MACRO
TV
SOURCE
AMP
TV
SOURCE
AMP
or
V-AUX/DOCK
DVD VCR DVR PHONO
DTV/CBL CD MD/CD-R
TUNER
POWER STANDBY
C B A
Note
Note
Note
V-AUX/DOCK
AV TV
1 2 3 4
DVD VCR DVR PHONO
DTV/CBL CD MD/CD-R
TUNER
POWER POWER
SCENE
POWER STANDBY
C B A
ENTER
DISPLAY
AUDIO MENU TITLE
RETURN
STRAIGHT
PURE DIRECT
A/B/C/D/E
PRESET/CH SET MENU
SRCH MODE
LEVEL
BAND
MEMORY
2
3
1
Indicates the
number of macro
steps entered
Flashes alternately so you can
set the next step
MCR 2: DVD
MCR 1: POWER
MCR 3: AUDIO
