109
En
Advanced setup
AD
V
ANCED
OPERA
T
ION
English
■ Remote control TUNER ID
REMOTE TU
Use this feature to set the TUNER ID of this unit for
remote control recognition.
Choices: ID1, ID2
• Select “ID1” when the remote control TUNER ID code
is set to “2602”.
• Select “ID2” when the remote control TUNER ID code
is set to “2610”.
Setting remote control TUNER ID codes
You need to set the remote control TUNER ID library
code for the remote control.
1
Set the operation mode selector to F
AMP or
F SOURCE and then press 5TUNER on
the remote control to select the tuner to
change the remote control ID.
2
Press and hold C
LEARN for about 3
seconds using a ballpoint pen or similar
object and the 9l / h repeatedly until
“L;TUN” and “TUNER” appear in the display
window (6) on the remote control.
• Be sure to press and hold CLEARN for at least 3
seconds, otherwise the learning process will start.
• If you do not complete each of the following steps within
30 seconds, the setting mode will be automatically
canceled. In this case, start over from step 1.
3
Press 9
ENTER.
The four-digit code set for the selected input area
appears in the display window (6) on the remote
control.
4
Press the numeric buttons (A) to enter the
four-digit remote control code for the input
area you want to use.
Remote control tuner ID codes
Select one of the following codes to set the remote control
tuner ID code for the input area you want to use.
5
Press 9
ENTER to set the number.
“OK” appears in the display window (6) if setting
was successful.
“NG” appears in the display window (6) if the
setting was unsuccessful. In this case, start over from
step 1.
6
Press C
LEARN again to exit from the setup
mode.
See page 107 for the operation of the advanced setup.
Notes
LEARN
ENTER
A/B/C/D/E
PRESET/CH
Tuner ID code
(remote control
setting)
Function
Remote
control
tuner ID
2602
(initial setting)
To operate this unit using the
default code. ID1
(initial setting)
2610 To operate this unit using an
alternative code. ID2
4 3 2
0 9
5
1
7 6 8
STEREO
MULTI CH IN
SUR. DECODE PARAMETER
CLASSICAL LIVE/CLUB ENTERTAIN
ENHANCER
MOVIE
LEARN
