The ceramic hobs are thermostatically controlled with
a 6 level commutator.
One of the stage is the "Off" position. The application
field of the six remaining stages are given in table.
Fast radiantdual or extended type hot plates are
energy regulating type. They adjust the burner
operation time of the heater continuously between
1st to 3rd stages.
4.3 Operating the Ceramic hobs
Hob hot indicator lights
Show which hob is operating and/or hot. Indicator
lights will remain on whenever the hob is hot.
Whenever the temperature of the hob surface falls
below 64 degrees °C limit, the indicator light will go
off.
Do not touch and keep
children away from the
heating zones and
appliance at all times.
Corresponding cooking values
Energy
regulator stages
1 2 3
7 stages
commutator
1 2-3 4 - 5 - 6
Application
Position to Simmering Cooking-roasting
hold hot boiling
Dual or extended burners are energy regulating type adjusting the
operation time of the heater continuous between 1st to 3rd stages.
Dual burner can heat up at 2 different positions. Saving energy and
time can be achieved by lighting the 1st stage for small pots and the
1st and 2nd stages for large pots. By turning the burner knob clockwise,
the inner part of the burner will heat up. You can use the 1 st, 2nd
and 3rd stages according to the applications indicated in the table.
Keep turning the " ® •" knob in a clockwise direction starting from
the 3rd stage until a "click" sound is heard to use the interior and
exterior parts of the burner at the same time. Both stages of the burner
will operate. After the completion
of the cooking operation, set the knob to
"
0
"
position by turning it
in a counterclockwise direction.
Caution: The 2nd stage of your dual or extended burners will
not operate by itself.
2. stage
1 .stage
10
