Part 3:
Technical specifications
1.
Burners plate
2.
Control panel
3.
Front door
4.
Handle
5.
Storage compartment
6
.
Tray
7.
Grill shelf
8
.
Integral air oven
9.
Knob heat shield
2
There may also be plate location other than the ways shown
in the figures.
The fast radian, extended and dual plates
burn with
that brillant light when they are first ON.
A rapid heating solid plates
are as denoted by a red spot
in the centre of the plate.
The voltage, frequency and maximum powers shown in the
data plate .
Conventional cookers
Multi-function cookers Fan assisted cookers
Grill wattage
800/1500
800/1500
800/1500
Oven wattage
1900W
1900W
1900 W
Turbo wattage
_
1800W
_
Turbo motor wattage
-
+
+
Lamp
25 W
25 W
25 W
External dimensions
H: 850
H:850
H:850
W: 500
W: 500
W: 500
D: 600
D: 600
D:600
1.
0
140 1200 W Radian plate_____________
2.
0
140 1200 W Fast radian plate_________
3.
0
18Q 1
7QQ W Radian plate___________
4.
0
180 1800 W Fast radian plate
5.
0 140x250 2000 W Fast radian plate
6.
0
180 2000 W Rapid plate______________
in.
7.
0
145 1000 W Solid plate
8.
0
145 1500 W Rapid plate
(*)
9.
0
180 1500 W Solid plate
(*)
10.
0
80 450 W solid plate
11.
0
180 1000 W Solid plate_______________
12.
Rapid burner 2.9 kW ___________________
13.
Semi rapid burner 2.0 kW ______________
14.
Auxiliary burner 1.0 kW ________________
15.
0
120x180 700-1700 W dual plate
(*) protector
(
13
)
(
14
)
(13) (12)
®o
(3)
o©
0 ©
0 0
