Identifying parts and controls
ea Access lamp
es MEMORY OPEN button (p. 165)
ed LOCK switch (p. 37)
ef POWER switch
eg START/STOP button (p. 37)
eh DC IN jack (p. 25)
ej DC IN jack cover
ek MEMORY EJECT button (p. 165)
el “Memory Stick” slot (p. 165)
r; AUDIO/VIDEO jack (yellow) (p. 60, 122, 188,
203, 264)
ra i (headphones) jack (green)
When you use headphones, the speaker on
your camcorder is silent.
rs (LANC) jack (blue)
rd Jack cover (p. 60)
rf (USB) jack (p. 236)
rg S VIDEO jack (p. 60, 122, 188, 203)
rh DV Interface (p. 124, 144, 189, 204, 264)
ea
es
ed
ef
eg
eh
ej
ek
el rh
rf
rd
rg
rs
ra
r;
LANC
The LANC stands for Local Application
Control Bus System. The LANC control jack is
used for controlling the tape transport of video
equipment and peripherals connected to it. This
jack has the same function as the jack indicated
as CONTROL L or REMOTE.
Oбознaчeниe дeтaлeй и оpгaнов
yпpaвлeния
ea Лaмпочкa обpaщeния
es Кнопкa MEMORY OPEN (cтp. 165)
ed Пepeключaтeль LOCK (cтp. 37)
ef Пepeключaтeль POWER
eg Кнопкa START/STOP (cтp. 37)
eh Гнeздо DC IN (cтp. 25)
ej Кpышкa гнeздa DC IN
ek Кнопкa MEMORY EJECT (cтp. 165)
el Cлот для “Memory Stick” (cтp. 165)
r; Гнeздо AUDIO/VIDEO (жeлтоe) (cтp. 60,
122, 188, 203, 264)
ra Гнeздо i (головныe тeлeфоны)
(зeлeноe)
Пpи иcпользовaнии головныx тeлeфонов
звyк чepeз гpомкоговоpитeль нe
выводитcя.
rs Гнeздо (LANC) (голyбоe)
rd Кpышкa гнeзд (cтp. 60)
rf Гнeздо (USB) (cтp. 236)
rg Гнeздо S VIDEO (cтp. 60, 122, 188, 203)
rh Интepфeйc DV(cтp. 124, 144, 189, 204,
264)
LANC
LANC обознaчaeт cиcтeмy кaнaлa мecтного
yпpaвлeния. Гнeздо yпpaвлeния LANC иcпользyeтcя
для контpоля зa пepeмeщeниeм лeнты видeоaппapaтypы
и подключeнныx к нeй пepифepийныx ycтpойcтв. Дaнноe
гнeздо имeeт тaкyю жe фyнкцию, кaк и paзъeмы,
обознaчeнныe CONTROL L или REMOTE.
