sTeP 5
Prepare the Receiver Collar
(PiG19-10763)
There are two sets of Contact Points that can be used on your receiver. Your Receiver Collar comes with the short Contact Points installed.
The longer Contact Points should be used on dogs with long hair. Tighten the Contact Points using Test Light Tool
(5a) one-half turn beyond
finger tight. Check the tightness weekly.
To insert and Remove the Battery
Note: Do not install the battery while the Collar Receiver is on your pet.
1. Remove the screws with a
Philips screwdriver.
2. Remove the Battery Lid (5B).
3. Install a 9-volt alkaline battery (5C).
4. Replace the Battery Lid (5C).
5. Reinstall the screws. Do not
over-tighten the screws.
Replacement 9-volt alkaline batteries can be found at many retailers.
To set the stimulation level
Read all steps before attempting to set the Stimulation Level.
1. Remove the clear plastic cover with the edge of the Test Light
Tool to expose the Stimulation Level Button (5D).
2 With the battery installed, press the Stimulation Level Button
and release when the Receiver Indicator Light lights up (5e).
3. The Receiver Indicator Light will emit a series of flashes
representing the Stimulation Level.
4. Increase the Stimulation Level by pressing and releasing the
Stimulation Level Button within 5 seconds of the previous series
of flashes.
5. After setting the Stimulation Level, replace the cover to protect
the Stimulation Level Button.
The Stimulation Levels increase in strength from 1 to 5. Pushing the Stimulation Level Button while the Receiver Collar is on level 5 will cause
the Receiver Collar to revert to level 1. Refer to the Function and Response Table to choose the Stimulation Level that best fits your pet.
The Receiver Collar will emit a Warning Tone and vibrate whenever your pet enters the Warning Zone, no matter what stimulation level the
Receiver is set to. If your pet continues into the Stimulation Zone, and the Receiver Collar is set to level 2 or above, he will receive a Static
Stimulation. The Receiver Collar is equipped to automatically increase the level of Static Stimulation the longer your pet remains in the Static
Stimulation Zone if the Receiver is set at level 2 or above.
The Receiver Indicator Light acts as a low battery indicator, flashing every 5 seconds when battery replacement is required. Test your
Receiver Collar at least once a month to verify that it is functioning properly and that it activates the Boundary Wire.
Over stimulation Protection
In the unlikely event that your pet “freezes” in the Static Stimulation Zone, this feature limits the static stimulation duration to a maximum of 30
seconds. While the system locks out further static stimulation, the warning tone will continue until the pet leaves the Static Stimulation Zone.
5a 5B 5C
5D 5e
www.petsafe.net 141
