•Always use gradual turns at the corners with a minimum 1 m radius, to produce a more consistent boundary (2B). Do not use sharp turns, as this
will cause gaps in your boundary.
•Avoid making passageways too narrow for your pet to move about freely (e.g., along the sides of a house).
•The Receiver Collar can be activated inside the house if the Boundary Wire runs along the outside wall of the house. If this occurs, remove your
pet’s Receiver Collar before bringing him inside, decrease the range using the Boundary Width Control knob or consider an alternative layout.
sample layouts
2C
2D
sample 1:
Perimeter loop
(single loop)
The Perimeter Loop
is the most common
layout. This will
allow your pet to
freely and safely
roam your entire
property
(2C). It
can also protect
flower gardens and
landscaping
(2D).
D
E
A
C
B
2e
sample 2 (2e): Perimeter loop using existing Fence (single loop)
This layout allows you to include your existing fence as part of your layout
and keep your pet from jumping out or digging under your existing fence.
It reduces the amount of wire which will need to be buried. From the Fence
Transmitter, run the wire to
a, a to B, B to C, C to D, D to e, e to a, twist
the wires from a back to the Fence Transmitter. See the “Install the Boundary
Wire” section for more information on attaching the wire to a fence.
Double loop
A Double Loop must be used when you are not establishing the Boundary Zone on all sides of your property.
When using a Double Loop, the Boundary Wire must be separated by a minimum of 1.5 m to avoid canceling the signal. Remember that a
Double Loop will require twice as much wire.
E
F
B A
D
C
E F
C
A
D
B
1.5 m
1.5 m
2F
sample 3 (2F): Front or Back
Property Only (Double loop)
From the Fence Transmitter, run the wire to
a, a to B, B to C, C to D, D to e, e to F,
make a U-turn and follow your path all the
way back to
a, keeping the wire separated
1.5 m. Twist the wire from a back to the
Fence Transmitter.
B
A
1.5 m
2G
sample 4 (2G):
Front Boundary Only (Double loop)
From the Fence Transmitter, run the wire to
a, a to B, B back to a keeping the wire
separated
1.5 m. Twist the wire from a
back to the Fence Transmitter.
E
B
D
C
A
1.5 m
2H
sample 5 (2H):
lake access (Double loop)
From the Fence Transmitter, run the
wire to
a, a to B, make a U-turn and
go to C, C to D, D to e, make a U-turn
and follow your path all the way back
to
a keeping wire separated 1.5 m.
Twist the wire from a back to the
Fence Transmitter.
