How the system Works
A radio signal travels through a buried wire, marking the boundaries you wish to set for your dog. Your dog wears a Receiver Collar that
detects the signal at the boundary. As your dog approaches the boundary, the receiver issues a warning tone with vibration. If he proceeds
further, he receives a safe but startling Static Stimulation. While harmless, the Stimulation will persuade him to stay in the Containment Area
you’ve established. The Stubborn Dog Receiver Collar offers 5 levels of stimulation, adjustable to your dog’s temperament. This PetSafe
®
Stubborn Dog In-Ground Fence
™
System has been proven safe, comfortable, and effective for pets over 3.6 kg.
Key Definitions
Fence Transmitter: Transmits the radio signal through the Boundary Wire.
Pet area: Area within the Warning Zone where your pet can roam freely.
Warning Zone: Outer edge of the Pet Area where your pet’s Receiver Collar begins to beep, warning him not to go into the
Static Stimulation Zone.
static stimulation Zone: Zone beyond the Warning Zone where your pet’s Receiver Collar will emit a Static Stimulation, signaling him to
return to the Pet Area.
Boundary Width: Combination of the Warning Zone and the Static Stimulation Zone.
Receiver Collar: Receives the radio signal from the Boundary Wire.
stimulation level Button: Adjusts the level of Static Stimulation your pet receives in the Static Stimulation Zone.
Receiver indicator light: Indicates the level of stimulation at which the Receiver Collar is set. This light also serves as a low battery indicator.
Contact Points: Delivers the safe Static Stimulation when your pet moves into the Static Stimulation Zone.
Power jack: Where the Power Adapter plugs into the Fence Transmitter. The Fence Transmitter is powered by a standard outlet.
Boundary Control switch: Switch located on the Fence Transmitter to adjust according to the length of Boundary Wire used.
Boundary Wire Terminals: Where the Boundary Wires connect to the Fence Transmitter in order to complete a continuous loop.
loop indicator light: Indicates that the Boundary Wire makes a complete loop, enabling the signal to be transmitted.
Boundary Width Control: Adjusts the width of the Warning and Static Stimulation Zones. Note: Adjusting the knob does not change the
level of Static Stimulation on the Receiver Collar.
Static Stimulation
Zone
Fence
Transmitter
Warning
Zone
Static Stimulation
Zone
Warning
Zone
Boundary
Width
Pet Area
Stimulation Level
Button
Contact Points
Washers
Receiver
Indicator Light
Boundary
Control
Switch
Boundary Wire
Terminals
Loop Indicator Light
Power Light
Power
Jack
Boundary
Width Control
Receiver Collar
Fence Transmitter
