Walk toward the Boundary Wire with Contact Points pointing up and holding the Receiver Collar at your pet’s neck level (6e) until the
Receiver Collar beeps and the Test Light flashes (6F).
Note: The Receiver Collar is waterproof, which can make the beep hard to hear.
If the Receiver Collar does not beep at the desired range, adjust the Boundary Width Control knob to the desired setting. Turning the
Boundary Width Control knob clockwise increases the Boundary Width while turning it counterclockwise decreases it
(6B). Repeat this
activity as needed until the Receiver Collar beeps at the desired distance from the Boundary Wire.
Note: The flashing Test Light Tool, when held to the Contact Points, indicates the Receiver Collar is delivering Static Stimulation.
The numbers on the Boundary Width Control knob indicate signal strength and are not representative of Boundary Width footage. If adjusting
the Boundary Width Control knob does not give the desired range, adjust the Boundary Control Switch to another setting to achieve your
desired range. If using a Double Loop, you may need to increase the separation of the Boundary Wire to achieve desired range.
The Receiver Collar beeps as a warning tone and ticks when delivering a Static Stimulation. After
hearing the beep, continue to walk towards the wire. The Receiver Collar should tick and the Test Light
should flash, indicating the Static Stimulation as you enter the Static Stimulation Zone
(6G). A warning
tone and the flashing of the Test Light indicate that the Receiver Collar and the system are working
properly. Test in a number of different areas until you are satisfied that the system is functioning properly.
Next walk all around the Pet Area to ensure there are no areas where the Receiver Collar may activate
from signals coupled onto buried wires or cables. Test the collar in and around the inside or the house
as well. As mentioned, cable and wires from cable TV, electrical or telephone lines may conduct pet
fencing signals inside and outside the house that can activate the dog’s collar accidentally. While rare,
if this occurs your Boundary Wire is probably too close to these outside lines and should be moved or
modified as shown in figure
3a. If you are satisfied that your system is functioning properly, you are
ready to start burying the Boundary Wire. If the Receiver Collar did not beep or the Test Light did not
flash, see the “Troubleshooting” section.
Note: The Boundary Width is broken down into 20% Warning Zone and 80% Static Stimulation Zone.
sTeP 7
install the Boundary Wire
Underground cables can carry high voltage. Have all underground cables marked before you dig to bury your wire.
In most areas, this is a free service. Avoid these cables when you dig.
•Avoid damage to the insulation of the loop wire during the install. Damage may cause areas of weak signal and lead to
early failure of the loop (wire breaks).
•Before you begin installing the Boundary Wire, unplug the Fence Transmitter power adapter from the outlet.
To Bury the Boundary Wire
Burying the Boundary Wire is recommended to protect it and prevent disabling the system.
1. Cut a trench 2.5 cm - 7.6 cm deep along your planned boundary.
2. Place the Boundary Wire into the trench maintaining some slack to allow it to expand and contract with temperature variations.
3. Use a blunt tool such as a wooden paint stick to push the Boundary Wire into the trench. Be careful not to damage the
Boundary Wire insulation.
To attach the Boundary Wire to an existing Fence
The Boundary Wire can be attached to a chain link fence, split rail fence, or a wooden privacy fence. The Boundary Wire can be attached
as high as needed. However, make sure the Boundary Width is set at a high enough range for the pet to receive the signal. If using a Double
Loop with an existing fence at least 1.5 m tall, run the Boundary Wire on top of the fence and return it on the bottom of the fence to get the
1.5 m separation needed.
Boundary
Wire
6G
