Table and Fence Assembly - Exploded View
Table and Fence Assembly - Parts List
Index No. Part No.
Description
Size Qty
1 ............. 6430055.................... Handle ..................................................................................................... 1
2 ............. 3215301 .................. Lock Plate ................................................................................................ 1
3 ............. 6626031.................... Spring Pin ................................................................................................ 1
4
6813042 .................. Spring ......................................................................................................1
5
TS-0640081 ............ Nylon Lock Hex Nut .............................................5/16-18 ....................... 1
6
TS-0640071 ............ Nylon Lock Hex Nut ............................................ 1/4-20.......................... 2
7
3575080 .................. Pad...........................................................................................................2
8..............TS-0271031 ............ Socket Set Screw.................................................3.8-16x3/8................... 2
9..............3076232.................... Lock Handle............................................................................................. 1
10............TS-0152031 ............ Carriage Bolt........................................................5/16-18x1-1/2 ............. 1
11 ............PM1800-411 ............. Socket Head Button Screw ..................................1/4-20x1-1/4 ............... 1
