Power supply
Install a circuit-breaker near the oven in an easily accessible place. The distance between
the contacts must be at least 3 mm. Before connecting the cable to the power supply,
check if the network has sufficient power in relation to the maximum power drawn by the
oven according to the data given on the rating plate.
ATTENTION: During the installation process bear in mind the position of the power
cable. Avoid temperature over 50°C at any part of the cable. The oven meets the
safety standards established by the governing bodies.
The oven is safe to use, only if it was properly grounded according to binding
legal requirements for cable safety. You are responsible for grounding the oven
properly. The producer bears no responsibility for damages or injuries of people,
animals or property caused by improper grounding of the oven.
WARNING: Voltage and frequency are given on the rating plate. Cable and wiring
system must withstand the maximum power required for the oven, given on the
rating plate.
If you have any doubts, call in a qualified expert.
In order to connect the cable:
1 Unscrew the bolts holding the cable and three bolts of L-N-
2 Fasten the cables under the bolt heads.
Operating the oven
SETTING THE CLOCK
When the oven is plugged into the power source, you will see “00:00” on the display and
hear a single sound signal, after which the device will go into a standby mode.
1 Press the button – you will see hours’ digits on the display.
2 Turn the dial to set the right hour between 0-23.
3 Press the button – you will see minutes’ digits on the display.
4 Turn the dial to set the right minutes between 0-59.
5 Press the button to finish setting the clock. The “:” will start flashing and the clock
will be set.
ATTENTION: The clock is in a 24 h mode. When setting cooking time below
60 minutes, set the longer time first, and then turn the dial backwards to the
desired time.
SETTING A FUNCTION
1 Turn the dial to select the desired function. You will see a proper indicator
turn on.
2 Turn the dial to set the temperature.
3 Press the button to start the cooking process.
4 If you skip step 2, press the button to confirm immediate start. Time will be set
automatically to 9 hours, and the automatic temperature will be given on the LED display.
ATTENTION:
1 Threshold values to set by the coding dial are the following:
0 - 30 min : 1 minute
30 min - 9 hours : 5 minutes
2 The threshold value for temperature setting is 5 degrees Celsius.
3 Turn the dial to set the time for cooking during the process. Next press
the button to start cooking. If you press within the next 3 seconds, the
oven will go back to its previous time set and will continue cooking.
4 Turn the dial to adjust the temperature during cooking. A proper
indicator will turn on. Next press the button to start cooking. If you do
not press within the next 3 seconds, the oven will go back to its previous
temperature and continue cooking.
INQUIRING FUNCTION
During cooking process, you can use inquiring function, after 3 seconds return to the
current working state.
1 During cooking mode, press button to see the current time.
2 If the clock was set, press button to ask for current time.
CHILDREN SAFETY FUNCTION
Locking: In standby mode press the + buttons simultaneously for 3 seconds.
You will hear a long sound signal meaning the children safety lock is on – the following
indicator will be on:
.
Unlocking: In lock mode press the + buttons simultaneously for 3 seconds. You
will hear a long sound signal meaning the children safety lock is off.
REMINDER FUNCTION
The oven has 9 hours reminder, this function will help remind you to start cooking in
a certain time from 1 minute to 9 hours. Only when oven in standby mode, the reminder
can be set. Follow below to set the reminder:
1 Press reminder setting button .
2 Turn to set the hour time of reminder.
3 Press reminder setting button again.
4 Turn to set minute time of reminder.
Note: After the set time, the oven buzzer will sound for 10 times, then symbol
disappears on the screen to reminder you start cooking. You can cancel the
reminder during setting process by press stop button. If the reminder was set, you
can cancel it by press stop button twice.
Vents
ATTENTION: The fan works for 15 minutes after the oven has stopped working.
Vents
