18
4.2 Dry vacuuming operation
If the appliance has been used before for
wet/wash vacuuming, all the instructions in
this section must be followed.
Your TWIN AQUAFILTER is set up ex works for dry
vacuuming – in this case read from point
k
D onwards.
G Open the casing cover (1) by lifting the cover
release (4).
I Remove the dirty-water container assy. (24) by
its carrying strap and, if necessary, extract the
inserted anti-slosh insert (22).
H Insert the HEPA filter (20) into the appliance.
D Insert the AQUA filter assy. (42) behind both guide
ledges of the dirty-water container (24) until it
stops. Ensure that the seal around the AQUA filter
(42) is on the inside of the dirty-water container
(24) and that the wet filter (23) has been fitted.
Fill the dirty-water tank (24) with 1 litre of clear
water.
Insert the filled dirty-water container (24) into the
appliance and fold the carrying strap to the side.
Ensure that the carrying strap is not covering the
casing seal.
Slowly close the casing cover (1) so that the seals
and the connectors on the AQUA filter (42) are
not damaged.
C Attach accessories as required to the suction pipe
(34) or directly to the handle (29).
J Connect the mains plug (63).
B Switch on the appliance using the appliance on/
off switch (14).
C The suction power can be reduced using the
suction power regulator (supplementary air slide)
(29).
Suppl. air slide closed = full suction power, suppl.
air slide open = reduced suction power.
On carpet floors, a half-open supplementary air
slide will achieve the best water filter action and
prevent the nozzle from becoming blocked.
To achieve optimum filter action, we recommend
that you rinse the AQUA filter with clear water
and change the water in the dirty-water container
every 40-60 minutes of continuous operation or
whenever you see a large pool of water on the
underside of the cover.
After dry vacuuming
For reasons of hygiene, empty and clean
the AQUAFILTER system after each use. Dirty
water and moisture on the appliance parts
encourage bacteria and fungi to multiply.
Switch off the appliance using the main switch (14) and
pull out the mains plug.
G Open the casing cover (1) by lifting the cover
release (4).
D Remove the dirty-water container (24) from the
appliance by its carrying strap.
Remove the AQUA filter (42) from the dirty-water
container (24) by its handle and pour away the
dirty water (e.g. down the toilet).
E Remove the foam filter (43). To do this, gently pull
the frame (48) on the AQUA filter (42) upwards
and fold it away to the side.
D Clean the wet filter (23) if it is dirty.
Thoroughly wash the AQUA filter (42), the
foam filter (43), the wet filter (23) and the
dirty-water container (24) with clear water,
without any cleaning agent.
Ensure that the parts are completely dry
before replacing them in the appliance.
If impurities and fluff have clogged the suction filter (44,
illus. E), this can also be removed for gentle cleaning;
afterwards replace the suction filter in the appliance.
Remove impurities and fluff from the AQUA injection
nozzle (10, illus. G).
Cleaning the HEPA filter
Your TWIN AQUAFILTER has a high-quality HEPA
filter, which can be cleaned frequently as required and
according to the type of household dirt. This will ensure
that the appliance regains full suction power.
Cleaning should be carried out depending on the level
of usage and the reduction in suction power (at least
every 6 months).
H Remove the HEPA filter (20) from the appliance
and knock it on a firm surface.
If the dirt cannot be removed in this way, the filter
can also be washed with clear water, without
any cleaning agent, and then knocked on a firm
surface.
Never use a brush for cleaning. Ensure
that the filter is completely dry before
replacing it in the appliance.
When cleaning the HEPA filter (20), do not
damage the filter wires.
If the suction power of the appliance is not considerably
increased by cleaning the HEPA filter, the filter should
be replaced with a new one.
