08_
setting up
08_
setting up
Only connect the water line to a drinkable
water source.
If you have to repair or disassemble the
water line, cut off 6.5mm of the plastic tubing
to make sure you get a snug, leak-free
connection.
After the water supply has been installed
check all the joints to ensure there are no
leaks.
• Samsung Warranty does
not cover THE WATER
LINE INSTALLATION.
• The cost of the water
line installation is at the
customers expense, unless the retailer has
covered this expense in the delivery charge.
• Please contact a Plumber or Authorized Installer
for the installation if needed.
• If Water leakage occurs due to improper
installation, Please contact installer.
SETTING UP THE
REFRIGERATOR
Now that you have your new Refrigerator installed in
place, you are ready to set up and enjoy the features
and functions of the appliance. By completing the
following steps, your Refrigerator should be fully
operational.
1. Place the Refrigerator in an appropriate location
with reasonable clearance between the wall and
the Refrigerator. Refer to installation instructions
in this manual. (P8. Selecting the best location for
the Refrigerator)
2. Once the Refrigerator is plugged in, make sure
the interior light comes on when you open the
doors.
3. Set the Temperature control to the coldest
temperature and wait for an hour. The Freezer
will get slightly chilled and the motor will run
smoothly.
4. After powering the Refrigerator, it will take a few
hours to reach the appropriate temperature. You
can store food and drinks in the Refrigerator after
the temperature is suffi ciently cool.
1. First, shut off the main water supply line.
2. Locate the nearest cold, drinking water line.
3. Follow the Water line Installation Instructions in
the installation kit.
The water line must be connected
to the cold water pipe. If it is
connected to the hot water
pipe, it may cause the purifi er to
malfunction.
CAUTION
Connecting the water line to the
refrigerator
1. Remove the cap from water line on the unit and
insert compression nut to the water line on the
unit after disassembling from provided water line.
2. Connect both water line from the unit and water
line in the kit.
3. Tighten the compression nut onto the
compression fi tting. There should be no gaps
between
(A, B & C )
4. Turn water on and check for any leakage.
Close Main Close Main
Water pipe Water pipe
Close Main Close Main
Water pipe Water pipe
No gap No gap
Remove Remove
cap cap
Water Line Water Line
from unit from unit
Water Line Water Line
from unit from unit
No gap No gap
Loosen a Loosen a
CAUTION
