12_
setting up
12_
setting up
13. Place the hole in the
bottom of the freezer door
over the low hinge.
14. Replace the middle hinge connected to the freezer.
15. Insert and tighten the screw into the left and right middle
hinges with a philips screwdriver(+). Insert and tighten the 2
hex head bolts into the left and right middle hinges with an
allen wrench(Ø5mm).
16. Replace the cap on the middle hinge.
17. Place the hole in the
bottom of the left door
over the middle hinge.
18. Insert the left upper hinge
shaft into the hole on the
corner of the fridge door.
19. Insert the upper hinges
into the holes at the top of
the door.
Insert and tighten the 3
hex head bolts into the left
and right upper hinges with
a socket wrench(10mm).
20. Insert and tighten the
ground screw into the left
and right upper hinges with
a philips screwdriver(+).
21. Connect the electronic
wire on the top of the
refrigerator.
22. Position the top table in
place. Insert and tighten
the 3 screws into the
top table with a philips
screwdriver(+).
