operating _15
operating _15
02 OPERA
TING
PARTS AND FEATURES
Use this page to become more familiar with the
parts and features of the Refrigerator.
USING THE CONTROL PANEL
1
Ice Off Button
When the Ice Off button is pressed, ice will not be
produced.
Use this function only when it is needed.
2
Power Freeze
Press the Power Freeze Button. (Refer to the
picture.)
- The power Freeze light on the display goes on
(see the arrow mark) and this function begins to
operate regardless of the set freezer temperature.
Press the Power Freeze Button again to cancel this
function.
- The light goes off and it operates at the set
freezer temperature again.
- The Power Freeze function operates for 72 hours
regardless of the set temperature.
When you use this function, the energy
consumption will increase. This function must
be activated before putting large amount of
food stuff in the freezer compartment at least
48 hours before.
3
Freezer
If you want to control the freezer temperature, follow
as below.
Press the Freezer Button (Refer the picture)
- The temperature can be set in 1ºC interval
between -25ºC and -14ºC.
operating your samsung
refrigerator
Fridge
option
option
Freezer
Drawer Type
Swing Type
1
4
2
5
3
6
