setting up _11 setting up _11
01 SETTING
UP
How to reverse the door (OPTION)
Unplug the refrigerator or disconnect the power.
Refer to the page 9, 10 for disassembling the door.
1. Remove 2 screws.
2. Separate front leg Cover. 3. Separate the Cap of the
front leg Cover. (pull out
inside of Cap)
4. Insert the Cap on the other
side of the front leg Cover.
5. Remove 2 bolts of each
hinge with the 10mm
wrench.
6. Place them in front of each
side.
7. Separate low hinge shaft
by using 5/32” wrench and
disassemble low hinge leg
by turning it colockwise,
and then assemble the low
hinge by turning it over.
8. Reattach the former right
hinge on the left side and
the former left hinge on the
right side by using 2bolts.
9. Separate stopper by
removing 1 screw on the
right lower side of freezer
and assemble the stopper
on the left side by reversing
it.
10. The middle hinge for
reversing a door can be
found in the fridge.
11. Change the middle hinges
assembled at refrigerator
to the middle hinges in the
fridge with handles.
12. Use the black hinge
cap of the middle hinge
assembled at refrigerator.
Then place it at the bottom
of the left middle hinge
supplied separately.
Use the Flat-blade screwdriver(-).
Cap Cap
Cover Cover
Cap Cap
