operating _17 operating _17
02 OPERA
TING
3. Vegetable & Fruit Drawers
To remove - Pull the drawer out
to full extension.
Tilt up the front of
the drawer and pull
straight out.
To replace - Insert the drawer
into the frame rails
and push back into
place.
The drawers need to be removed before the
glass shelf above them can be lifted out.
To get the best energy effi ciency of this
product, please leave all selves, drawers
and baskets on their original position like as
illustration in page 15
REMOVING THE FREEZER
ACCESSORIES
1. Pull Out Drawer
To remove - Pull the drawer out to full extension.
Tilt up rear of drawer and lift straight
out. (Refer to picture 1 & 2)
Open the freezer door fully and remove the drawer.
To replace - Place the drawer onto the rails by tilting
it up. Lower the drawer into place until it
is horizontal and slide the drawer in.
(Refer to picture 3)
2. Freezer Drawer Bin
Swing-Type
To remove - Pull the drawer out
fully. Tilt up the rear
of the bin and lift it
out to remove.
To replace - Place the bin into the
rail assembly.
When replacing, place the drawer
bin holder into the hole of the rail
Twist Ice Maker Model
1. Pull out the Ice-cube trays.
2. Fill trays up to the water level mark(arrow).
3. Put the Ice-cube trays back in position. And close
the freezer door.
4. Once the water has become frozen, turn the dials
on the Ice cube trays to empty Ice cubes into the
storage bin.
REMOVING AND RELOCATING
THE FRIDGE ACCESSORIES
1. Door Bins
To remove - Simply lift the bin up
and pull straight out.
To replace - Slide it in above the
desired location and
push down until it
stops.
Injury may occur if the door bins are not fi rmly
inserted. Do not allow children to play with
bins. Sharp corners of the bins may cause
injury.
Empty the bin before adjusting it.
Dust removal method -Remove the guard and wash
in water.
2. Fridge shelves
To remove - When pulling out the
shelf, if it does not
slide out easily, lift it
up slightly and pull
out again.
To replace - When pushing in the shelf, if it does not
slide in easily, lift it up slightly and push
in again.
The Glass shelves are heavy.
Use special care when removing them.
1 1 2 2
4 4 3 3
CAUTION
CAUTION
1 1
2 2
3 3
3 3 1 1 2 2
1 1 2 2
2 2
1 1
