35
Plug
GAS TYPES
The gases used for the operation of
cooking appliances may be grouped by
their characteristics into two types:
Cat:
II
2H3+
– NATURAL GAS (G 20)
– L.P.G. (in cylinders) (G 30/G 31)
GAS CONNECTION
The connection must be executed by a
qualified technician according to the rel-
evant standard:
The appliance is predisposed and cali-
brated to operate with the gas indicated
on the specifications plate.
Make sure that the room where the cook-
er will be installed has adequate ventila-
tion, in conformity with the rules in force,
so that the appliance can work correctly;
then connect the cooker to the cylinder
or gas pipe respecting the rules in force.
The connection must be executed to the
rear of appliance (left or right) (fig. 8.1);
the pipe do not cross the cooker.
The unused end inlet pipe of the cooker
(left or right) must be closed with the plug
interposing the gasket.
If the appliance must be operated with a
gas different than that indicated on the
plate, it is necessary to execute the fol-
lowing operations:
- Gas connection.
– Replacement of the top injectors.
– Adjustment of the minimum of the top
burners.
GAS SECTION
8
The walls adjacent to the cooker
must be of material resistant to
heat.
Before installation, make sure that
the local distribution conditions
(type of gas and its pressure) and
the adjustment of this appliance
are compatible. The appliance
adjustment conditions are given on
the plate or the label.
Fig. 8.1
