10
GRATE FOR SMALL PANS
(fig. 2.4)
This grate is to be placed on top of the
(smaller) auxiliary burner when using
small diameter pans, in order to prevent
them from tipping over.
Fig. 2.3
BURNERS POT DIAMETER
Auxiliary (*) 12 - 14 cm
Semi-rapid 16 - 24 cm
Rapid 24 - 26 cm
Triple-ring 26 - 28 cm
do not use pans with concave
or convex bases
(*) with grill for small cookware:
minimum diameter 6 cm
It is important that the base diameter of
the pot is at least the same diameter as
the burner ring to obtain an efficient heat
transfer.
Always position pans centrally over the
burners.
Adjust the size of the flame so that it
does not lick up the side of the pan.
Position pan handles so that they
cannot be accidentally knocked.
CHOICE OF THE BURNER
On the control panel, near each knob,
there is a diagram that indicates which
burner is controlled by that knob.
Select the burner that is most suitable
for the diameter and capacity of the pan
to be used.
As an indication, the burners and the
pans must be used in the following
way:
Fig. 2.4
