In models with " covered terminal block"
In mix models a cable supplied with a plug with your oven (H05 V V-F 3G
1,5 mm2)
^ If a cable without a plug Is provided together with
your oven (HOS V V-F 3G 2,5 mm2 }
Take care to connect as below:
Brown cable = L (Live)
Blue cable = N (Neutral)
Greer^/Yellow cable = E (Earth )
//
your oven is supplied without supply cord use scbema-l to choose
supply cord and
use
schema-ll for Installation of cord.
The cable length should be max 2m long for isolation safety.
»- Open the terminal block cover (1).
•• Connecf
the supply cable according to wiring diagram on the rear cover,
^Assembly the terminal block cover to its place.
The mains cable must pass through the cable clamp (2).
Fix the supply cable to main body with two screw via cable tightener (2).
Your oven is suitable for single and three phase connection.
^The mains cable should be routed away from the appliance and in
particular ventilation slots, the vent outlet and should not be
obsirucfed
when
pushed in to position between the appliance and the wall and/or cabinet.
■ 0
■ Э-0
о
-Hoo
L>0
— ЭЮ
AC 22tV230^40V
0-0
0-0
■ oo
-P'00
L>0
— ОЮ
3N AC ЭвйАЮШ415 V
-p-OO
Loo
—oo
-P'00
L>0
— OiO
£NAC30OWDD/415V
Schema
II
Connection Type Monophase Three phase
with Neutral
Two phase
with Neutral
Voltage 220/230/
240 V 380/400/415 V 380/400/415 V
Supply cord type
(max 2m long)
3x2,5 mm2
H05 V V-F 5x2,5 mm2
H05 V V-F
4x2,5 mm2
H05 V V-F
Schema I
Ì50
Adjacent side walls above the
appliance must not be nearer
to the cooker than 150 mm
and should be of heat resistant
material. Leave at least 750
mm clearance above the
hotplates.
The appliance should be
located on
a
level surface.
The two front feet can be
adjusted as required. To
ensure
that your
oppA'once
is
standing level adjust the two
front feet by
fuming
clockwise
or counterclockwise until the
product is in firm contact with
the floor.
