Part 3: Technical specifications
1. Burners plate
2. Control panel
3. Front door
Conventional cookers Multi-function cookers Fan assisted cookers
Grill wattage 800/1500 800/1500 800/1500
Oven wattage 1900W 1900W 1900W
Turbo wattage - 1800W -
Turbo motor wattage - + +
Lamp 15W/25W 15W/25 W 15W/25W
External dimensions H:850 H:850 H:850
W: 500 W: 500 W: 500
D:600 D:600 D:600
There may also be plate location other than the ways shown
in the figures.
The fast radian, extended and dual plates burn with
that brillant light when they are first ON.
A rapid heating solid plates are as denoted by a red spot
in the centre of the plate.
The voltage, frequency and maximum powers shown in the
data plate .
1. 0 140 1200 W Radian plate______________
2. 0 140 1200 W Fast radian plate__________
3. 0 18Q 17QQ W Radian plate_____________
4. 0 180 1800 W Fast radian plate
5. 0 140x250 2000 W Fast radian plate
6. 0 180 2000 W Rapid plate (*)
8. 0 145 1500 W Rapid plate (*)
9. 0 180 1500 W Solid plate (*)
10
. 0 80 450 W solid plate
7. 0 145 1000 W Solid plate
11. 0 180 1000 W Solid plate_______________
12. Rapid burner 2.9 kW ___________________
13. Semi rapid burner 2.0 kW ______________
14. Auxiliary burner 1.0 kW ________________
15. 0 120x180 700-1700 W dual plate"
16. 0 160 1500 W Radian plate_____________
(*) protector
