ENGLISH
Charging Time and Maximum Time for
Continuous Recording in the Manual
Recording Mode
Battery
No.
Charging Time
Max. Continuous
Recording Time
Supplied 60 min. 50 min.
VW-VBS10E 65 min. 55 min.
VW-VBS20E 130 min. 110 min.
VW-VBH10E 80 min. 65 min.
VW-VBH20E 160 min. 130 min.
(The times shown in the above chart are approximations.)
•Maximum Continuous Recording Time means the
duration of continuous recording performed at an
ambient temperature of 20°C and 60% relative humidity.
In actual recording, however, the use of the zoom and
other functions increases the power consumption, and
higher or lower temperatures reduce the Battery’s ability
to generate electricity.
Therefore, the actual recording time per Battery may be
approximately 30%-50% shorter than listed above.
■ Using the Charge Confirmation Marker
You can use this marker to easily distinguish between
charged and discharged Batteries.
For example, slide the knob so that the red dot Q is
visible after charging is completed.
Contains a Nickel-Cadmium Battery. Must be
recycled or disposed of properly.
