When connecting to separately sold power amp

The navigation unit

Front output
(FRONT OUTPUT)

Rear output
(REAR OUTPUT)

25 cm

30 cm

30 cm

30 cm

RCA connector

Subwoofer output
(SUBWOOFER OUTPUT)

To system control terminal of the power amp
(max. 300 mA 12 V DC).

Blue/white

Connecting the System

Engb

14

Section

03
