KORTING HG695CTX - Инструкция (Страница 28)

Pan diameter table
Type of burner
Type of hob
All models 60 cm front control
Min. 0, mm Max. 0, mm Min. 0, mm Max. 0, mm
Auxiliary
60
with reducer
140
60
with reducer
140
Semi-Rapid 160 200 160
front - 180
rear - 200
Rapid 200 240 160 200
Triple Ring 240 260 200 220
USING THE GRIDS
The grids are designed to make the appliance easy and safe to use.
Ensure that the grids are properly positioned before using the appliance.
Furthermore, make sure that the protective rubber feet are correctly positioned.
Adapter grid for small pots or pans (figure 10).
The Grid for small pots or small pans is placed on top of the auxiliary burner grid (the smallest one) for pots
or pans of reduced diameter, used to prevent small pans from falling and to secure a balanced position of the
smaller cookware.
o
Figure 10. Figure 11.
Special “WOK” support grid (Figure 11) - optional.
The WOK support grid is placed on top of the triple crown burner when using a “WOK” pan, with rounded
bottom.
Never use a Wok pan without this special grid and never use the wok grid for flat-bottom cookware.
CLEANING AND MAINTENANCE
The appliance does not require any particular maintenance, except regular cleaning.
Anyhow, it is recommended to make the appliance checked by qualified personnel once every 2 years.
If the knobs become difficult to turn, or if there is a gas smell, close the gas supply and call the Service
centre immediately.
Faulty knobs must be replaced along with their gasket.
To maintain the hob in good conditions, clean it regularly after every use.
Let it cool down before cleaning.
Never use abrasive or sharp substances or materials to clean the surface of the hob.
Never clean the appliance with high pressure water or steam cleaning equipment.
Do not use flammable or alcoholic cleaners.
26
