mAmmmm
(-» 18,24)
3
[
AOPEN]ffi >
’
jlSiS
’ a# ■ Wimsm
4
Harnm^fim ’ mm [^
eject
]
(il№)
ffi© °
5
mxmwM ’
-
mnmm
)i °
6
- ^itS[LOCK] fflO °
^ii±i«
mibmmmm
■ ;ts [
a
BEcrjo^tb)«® •
-
g?[LocK] iao ■
„
2
3
4
5
Inserting the Cassette
1
Connect the AC Adaptor or attach a
charged Battery. (-^ 18, 24)
Turn the cog wheel O to tighten the tape.
Slide the [AOPEN] Lever to the left and
simultaneously open the LCD Monitor in the
direction of the arrow approximately 90*".
• Be sure to keep the LCD Monitor in its vertical
position, so that Cassette Compartment Cover,
when it opens, does not hit the LCD Monitor.
Slide the EJECT] Lever 0 in the
direction of the arrow.
Insert the cassette with the cassette
window
0
facing outward and push it all
the way in.
6
Close the Cassette Compartment by
pressing the [LOCK] Button Q.
• It is not possible to take out the cassette during
recording.
• Do not insert and take out the cassette repeatedly. This
could cause the tape to become loose or damaged.
• If a cassette with broken out erasure prevention tab is
inserted, the [[^] Indication flashes.
Ejecting the Cassette
Slide the [A EJECT] Lever
0
in the direction of the
arrow and pull out the cassette.
Close the Cassette Compartment by pressing the [LOCK]
Button 0.
42
