Indications
■ Warning/Alarm Indications
0 Condensation (-♦ 176)
0 Video Head Clogging (-^ 176)
© Remaining Battery Power
When the remaining battery power is used up, the Movie
Camera automatically switches off. Replace the Battery with a
fully charged one.
0 Cassette
No cassette is inserted. Or the tab of the inserted cassette is
broken out. Insert a cassette with an intact tab.
Q
Built-in Lithium Battery (-^ 56)
The built-in Lithium Battery is exhausted. Charge it.
0End of the Tape
When the tape has reached its end, this indication appears.
Insert a new cassette.
0 Anti-Ground Recording 86)
0 General Warning/Alarm Indication
If you have selected the Mirror Mode
{-> 142)
on the [MAIN
MENU2] Menu and record with the LCD Monitor facing
forward, this indication appears instead of the actual Warning/
Alarm Indication and Error Code.
0
Error Code
(Error codes are information for service personnel.)
If the [F] Indication with a 2-digit number appears, a
malfunction has occurred.
If the indicated error code is between [F01] and [F05], the
Movie Camera will turn off automatically one minute after the
[CAMERA] Lamp has started to flash.
If the indication is [F51] or [F52], the Movie Camera will not
turn off automatically.
F01; Locked Take Up-Reel
F02: Locked Supply-Reel
F03: Locked Unloading Mechanism
F04: Locked Loading Mechanism
F05: Locked Cylinder
F51: Locked Focus Motor
F52: Locked Zoom Motor
