Qlii
12
:
30:45
15.10.1008
12:30:45
15.10.1998
ENGLISH
Using the Finder
Before using the Finder, adjust it to your eyesight so that
the indications in the Finder are clear and easy to read.
1
Set the [POWER ON/OFF] Switch to
[ON].
2 Slide the Finder backward.
The angle of the Finder can be adjusted upward.
However, be sure to slide the Finder backward until it
stops, before turning it upward.
3
Adjust by sliding the Eyepiece
Corrector Knob Q-
You can adjust the brightness of the Finder on the
Menu. {-¥ 126-130, 138)
Using the LCD Monitor
It is also possible to record while viewing the picture on
the opened LCD Monitor.
1
]
Set the [POWER ON/OFF] Switch to
[ON].
Push the [PUSH OPEN] Lever and turn
out the LCD Monitor approximately 90°
in the direction of the arrow.
The Finder turns off.
Adjusting the Angle
3 Adjust the angle of the LCD Monitor
according to the desired recording
angle.
♦ The LCD Monitor rotates upward a maximum of
180“ Q and downward a maximum of 90“ O
its normal vertical position. Trying to forcefully
rotate it beyond this range could seriously damage
the Movie Camera.
• You can adjust the colour level and brightness of
the LCD Monitor on the Menu. {-¥ 126-130, 138)
Closing the LCD Monitor
Push the LCD Monitor close until the [PUSH OPEN]
Lever locks with a click.
1
m
[POWER ON/OFF]
[ON] »
(-M 26- 130’138)
m-
m
[POWER ON/OFF]
[ON]
[PUSH OPEN]
m -
♦
■ [nj±s£
11180° @W^Tffil|90° ® °
(-»126- 130’138)
iifflHinii/TxSiits ’ as [PUSH oPENiffinfns-siia
■26-
