Filter holder
Wash the purifier filter with water.
1
2
Wash the water tank (excluding the purifier filter) with water.
Ice tray and pipe
Cleaning is normally not required.
Slime bacteria and fungus can become stubborn once they build up.
Clean on a regular basis to prevent slime bacterial and fungus build-up.
Do not use detergent or bleach.
(Use a soft sponge when using.)
Disassemble and wash each part using a sponge soaked with neutral detergent (dishwashing detergent).
Do not bend or poke with stick, etc.
Do not wash by rubbing.
When using bleach, be sure to follow the accompanied directions.
This may lead, the detergent may accumulate within
the filter or the active charcoal may become ineffective.
If the refrigerator has not been used for a long time, perform "Cleaning the ice tray". (58 page)
Replacement period of the purifier filter
Normally, replace the filter every 3 ~ 4 years.
Replacement is also required when there is
fungus, rip or odor on the purifier filter.
Contact the Sharp Service Center when ordering
a purifier filter.
Ice making capability will not change even when
the purifier filter is not used.
Notes
Notes
Purifier filter
Thoroughly clean the
packing groove as it
is easily dirtied.
From here
Remove the
water tank cap. Remove the lever and lid.
Mount the tab on
one side and press
in hard.
Disassembly Reassembly
1
Remove the packing
of the lid. 5
2
Mount the purifier filter and filter
holder to the filter case. 2
5
Mount the packing to the lid. 1
Lever
Lid Pull up
straight.
Tabs
(4 locations)
Remove the filter case.
Press in both side and
remove from the tabs.
Pull upward.
Pull down straight.
Remove the filter holder and
purifier filter.
Purifier filter
Filter holder
Remove the tabs by
placing the filter holder
sideways.
Tab
3
4
Mount the filter case. 3
Mount the lid. 4
Filter case
Hole
Hole
Tab
Tab
Close the water tank cap.
40
Cleaning the automatic ice maker
(Once a week)
