Carpet
Air
Air
Fix to a sturdy wall or pillar to
prevent the refrigerator from
falling over.
Installing on unstable surface will
cause vibration and noise.
Remove the evaporating pan cover
by pulling diagonally upward.
Turn the adjustable feet on both
sides until they reach the floor.
(Adjust so that the refrigerator
becomes level)
Lastly, insert the tabs on both sides
of the evaporating pan cover into
the holes of the unit.
Using the two front Adjustable feet,
ensure that the refrigerator is
positioned firmly and level on the floor.
Audio and video noise may be noticed on radios, televisions, etc. when using near the refrigerator.
Move radios, televisions, etc. to a location where audio and video noises are not noticed. Noise may be
louder in case the refrigerator is not grounded.
Do not install screws, etc. on the refrigerator. Cooling circuit (pipes) may become damaged as a result.
Notes
Select a location.
Place a sturdy board in the
case of following:
Do not place directly on a
carpet as this will cause
the intake and discharge
ports on the bottom of the
refrigerator to become
blocked.
1
2
3
4
Use the hole
for passing
ropes.
Do not place objects on top of the refrigerator.
Top of the refrigerator is built with a plasmacluster OUT ionizer. Placing object on top of the refrigerator
may block the intake port or damage the device.
Space is also needed
for cleaning the top
filter.
Top
9cm or more
Sides
6cm or more
6cm or
more
Evaporating pan cover
Tab
Right/left
adjustable foot
Hole
To ensure adequate ventilation for your refrigerator, it is
recommended to provide space of 6cm on both sides and
at the back, and space of 9cm above the refrigerator.
Insufficient spacing will decrease the cooling efficiency,
resulting in unnecessary consumption of electricity.
Position your refrigerator so that the plug is accessible.
Do not place next to heat generating appliance.
Keep your refrigerator out of direct sunlight.
Do not place directly on the ground. Provide a clean, level,
firm floor surface such as concrete or timber.
Installation
27
Caution / Installation
ENGLISH
