Case
Notes
Shelves cannot be removed if
some cases if the doors cannot
be opened fully (more than 90
°).
Do not remove accompanying
parts with foods stored.
Accompanying parts become
heavy and injury may occur as a
result of foods and parts dropping.
Do not leave the refrigerator
doors open for a long time.
The compartment lamp cover
will become hot.
Shelf
Pull up the front side
and pull out. Place the back side of the shelf on the rails
and insert by fitting the tabs on the front rails.
Freezer cases
Pull out and pull up
slightly to remove. Place the tabs of the case
on the rails and push in.
Removing
Removing
Mounting
Mounting
Tab
Rail
Freezer case
Push in the front section
into the back section, Put in the right and left
tabs as shownm, Pull the front
section.
Three position adjustable shelf
Press in the
front section, Pull up to remove. The front section and
the back section.
Tabs Back section
Front section
Removing
Mounting
Ice case
Pull up to remove. Insert the case along the
rail and close the door.
Removing
Fit on rail
Mounting
37
Chilled case
Pull out to remove.
Place the longer
case on the left.
Removing
Mounting
Long
Short
Removing and mounting accompanying parts
Food
ENGLISH
