LSM/LTM Series Installation Instructions
5
TOOLS REQUIRED FOR INSTALLATION
PARTS
7/32" (5.5mm) Wood Stud
#2
5/16" (7.9mm) Concrete
C (6)
E (6)
R (1)
W (1)
X (1)
S (1)
(LTM Only)
U (1)
3/16" - 6"
[A-P included with LSMU/LTMU Models Only]
A (8)
M4x16mm B (6)
M4x20mm M4x25mm
D (6)
M5x16mm
M5x20mm
F (6)
M5x25mm
G (6)
M6x16mm
H (6)
M6x25mm
P (1)
M5
I (6)
M8x20mm
J (6)
M8x30mm
K (4)
M8x50mm
L (8)
.750x.323x.250
M (8)
.750x.344x.500
QA (4)
5/16"
QB (4)
5/16"
QC (4)
5/16" x 2-1/2"
V (4)
Y (1)
Z (1)
Custom
LSM5XXX/
LTM5XXX
Hardware
[Included with
LSM5XXX/LTM5XXX
Models Only]
T (1)
(LSM Only)
[In bag
labeled "N"]
[Universal
washer]
N (8)
(LSM Only)
[Security bracket]
[Mount]
[Security bracket]
[Interface brackets]
(LTM Only)
[Interface brackets]
[Wall bracket caps]
