MSA/MTA Series Installation Instructions
5
TOOLS REQUIRED FOR INSTALLATION
PARTS
#2
7/32” (5.5mm) Wood Stud
5/16” (7.9mm) Concrete
M5
(included)
Custom
MSA6XXX/
MTA6XXX
Hardware
[Included with
MSA6XXX/MTA6XXX
Models Only]
C (6)
E (6)
(MSA Only) (MTA Only)
T (1)
S (1)
(MSA Only)
(MTA Only)
A (8)
M4x16mm
B (6)
M4x20mm M4x25mm
D (6)
M5x16mm M5x20mm
F (6)
M5x25mm
G (6)
M6x16mm
H (6)
M6x25mm
P (1)
M5
I (6)
M8x20mm
J (6)
M8x30mm K (4)
M8x50mm
L (8)
.750x.323x.250
M (8)
.750x.344x.500
N (8)
QA (4)
5/16”
QB (4)
5/16”
QC (4)
5/16” x 2-1/2”
[A-N used on MSAU/MTAU Models Only]
R (1)
U (1)
V (1)
W (1)
X (1)
[Wall bracket]
