Installation Instructions MSA/MTA Series
3
DIMENSIONS
12.00 304.8
9.58 243.4
.75 19.1
1.50 38.1
25.57 649.5
18.75 476.2
1.50 38.1
.34 8.6
11.00 279.4
16.00 406.4
8.00 203.2
13.50 342.9
4.83 122.6
12°
1.40 35.5
1.06 27
.32 8.1 .38 9.5
16.50 419.1
0
.45 11.5
1.97 50
2.42 61.5
3.94 100
4.39 111.5
5.91 150
6.36 161.5
7.87 200
.45 11.5
1.97 50
2.42 61.5
3.94
NOTES:
MAX MOUNTING PATTERN IS 22"[558.8mm] WITHOUT REVERSING UPRIGHTS. 1.
MAX MOUNTING PATTERN IS 26.5"[673.1mm] WITH REVERSING UPRIGHTS. 2.
FOR RECESSED APPLICATIONS, MINIMUM VERTICAL LIFT FOR HOOK 3.
ENGAGEMENT IS .56"[14.2mm].
MOUNT RAILS CAN BE SLID LEFT OR RIGHT FOR OFFSET APPLICATIONS. 4.
MOUNT IS 1.99"[50.5mm] DEEP WHEN FLAT TO WALL.
MTA
DIMENSIONS: [MILLIMETERS]
INCHES
25.57 649.5
18.75 476.2
.75 19.1
1.50 38.1
1.50 38.1
.34 8.6
9.58 243.4
11.00 279.4 13.50 342.9
16.00 406.4
8.00 203.2
1.96 49.8
13.50 342.9
16.78 426.1
.32 8.1 .38 9.6
.65 16.5
.98 25
0
.49 12.5
1.97 50
2.46 62.5
3.94 100
4.43 112.5
5.91 150
6.40 162.5
7.87 200
.49 12.5
1.97 50
2.46 62.5
3.94
NOTES:
MAX MOUNTING PATTERN IS 22.9"[581.6mm] WITHOUT REVERSING UPRIGHTS. 1.
MAX MOUNTING PATTERN IS 25.5"[647.7mm] WITH REVERSING UPRIGHTS. 2.
FOR RECESSED APPLICATIONS, MINIMUM VERTICAL LIFT FOR HOOK 3.
ENGAGEMENT IS .56"[14.2mm].
MOUNT RAILS CAN BE SLID LEFT OR RIGHT FOR OFFSET APPLICATIONS. 4.
MOUNT IS 1.96"[49.8mm] DEEP WHEN FLAT TO WALL.
DIMENSIONS: [MILLIMETERS]
INCHES
MSA
