31
9 Приложение
VEGADIS 81 •
43814-R
U-130612
ø 29...60 mm
(1.14"...2.36")
82 mm (3.23"
)
15 mm (0.59"
)
97 mm (3.82"
)
20 mm
(0.79")
M6
2 mm (0.08"
)
20 mm (0.79"
)
2 mm (0.08"
)
20 mm
(0.79")
48...84 mm
(1.89"...3.31")
Рис. 24: Зажимы для монтажа VEGADIS 81 на трубе
