Fagor 5CF-56MSPB - Инструкция (Страница 29)

EN
Problem Solution
Igniters fail to ignite or not always ignite
the gas
13.1.1 13.1.2
Check to make sure the cooker is connected to the electrical mains.
Clean and dry the igniters and burner components.
Check to make sure the burner caps and heads are placed correctly.
Press on the burner cap and rub it against the head by turning right
and left(fig. 13.1.1).
Rub the igniter electrode with the use of hard brush or smooth file (fig.
13.1.2).
Gas burners fail to ignite Check to make sure the rubber hose supplying gas from the gas cylin­
der is not squeezed.
Check to make sure the gas main valve is open.
Check to make sure the gas cylinder is not empty.
In case a new cooker has been installed or the gas cylinder has been
replaced with a new one, then it is necessary to repeat the ignition
procedure until the gas reaches the burner.
Check to make sure the nozzle or burner fiame holes are not clogged
or fiooded. If so, un-clog the nozzle hole using a pin or needle. Clean
the burner fiame holes with the use of brush, and then dry all compo­
nents.
Flame dies after releasing the knob Your cooker is equipped with a flame failure safety device
- Where the ignition device is built in the knob set the_knob to large fla­
me A, press the knob and when the gas has ignited keep it pressed
all the wav in for another few seconds. .
While igniting one of the burners all the
hob burner igniters spark
It is normal
When pressing the selected knob (with a built-in ignition device) or the
ignition button sparks are re-leased at all the burners .
After setting the knob to simmering flame
position A - the flame dies or is too high
- Avoid draughts in the kitchen,
- Call the fitter to adjust simmering flame position A .
Flame is unstable
Check to make sure that the burner components are clean, dry and
placed correctly.
Parts made of stainless steel (inox) deve­
lop stains that cannot be removed with the
use of standard cleaners Stainless steel surfaces should be cleaned each time they get soiled
and only with the use ofspecial stainless steel cleaner.
28
