1
2
3
Glass lid
Hinge sheet
Plastic part
Taking off the door inner glass
The inner glass panel of the oven door
can be removed for cleaning.
1 . Open oven door.
Remove metal part (1) by
unscrewing three screws that hold
the metal part.
Remove plastic holders (3) on left
and right hand side by pulling
towards yourself.
...«
' ................
4
3
2
1
2
3
Metal part
Inner glass
Plastic holder
4 Plastic housing
• Take off the inner glass, by pulling
towards yourself until inner glass
(2) free of plastic housing (4).
• To reassemble the inner glass;
take care, place the glass to
plastic housing and ensure that the
inner glass is positioned correctly
in the plastic housing.
Replacing the oven lamp
A Hot surfaces may cause burns!
Make sure that the appliance is
switched off and cooled down in
order to avoid the risk of an
electrical shock.
The oven lamp is a special
electric light bulb that can resist
up to 300 °C. See
Technical
specifications, page 5
for details.
Oven lamps can be obtained
from Authorised Service Agents.
0] Position of lamp might vary from
the figure.
If your oven is equipped with a
round lamp:
1 .
2 .
Disconnect the product from mains.
Turn the glass cover counter
clockwise to remove it.
i í
3.
4.
Remove the oven lamp by turning it
counter clockwise and replace it
with the new one.
Install the glass cover.
26| EN
